Specifications
Model Specification Table
| Parameter | Value | Unit |
|---|---|---|
| Maximum Turning Diameter | Ø1,150 | mm |
| Maximum Turning Length | 950 | mm |
| Chuck Size | 40 (Opt. 32 / 50) | inch |
| Spindle Bore | Ø240 | mm |
| Spindle Speed | 630 | rpm |
| Spindle Motor Power | 55 / 45 (73.5 / 60) | kW (HP) |
| Number of Turret Stations | 12 | stations |
| Axis (X/Y/Z/B) | X: 610 / Z: 950 | mm |
| CNC Controller | Fanuc 0i-TF Plus | — |
| Turnmill | 7.5 / 5.5 (10 / 7.5) or 11 / 7.5 (15 / 10), 3,000 | kW (HP), rpm |
| Turret | CAPTO C6: 12 / CAPTO C8: 10 | stations |
Core Capabilities
Complete Machining Capabilities
Achieve precision and efficiency with full multi-axis machining in a single setup.
