Specifications
Model Specification Table
| PARAMETERS | VALUES | UNITS |
|---|---|---|
| Swing Over Bed | 1120 ~ 2000 (44 ~ 78.74) | mm (inch) |
| Swing Over Cross Slide | 710 ~ 1590 (27.95 ~ 62.59) | mm (inch) |
| Distance Between Centers | 1500 / 2000 / 3000 / 4000 / 5000 / 6000 / 7000 / 8000 | mm |
| Spindle Bore | Ø 152 (6) | mm (inch) |
| Spindle Speed Range | 4–420 | rpm |
| Main Motor Power | 20 (15) | HP (kW) |
| Bed Width | 810 (32) | mm (inch) |
Core Capabilities
Complete Machining Capabilities
Achieve precision and efficiency with full multi-axis machining in a single setup.
