Specifications
Model Specification Table
| ITEM | e10 c153 | e10 c153 za | e10 c303 | ec1 |
|---|---|---|---|---|
| Marking window (mm) | 160 x 100 | 160 x 100 | 300 x 150 | 120 x 100 |
| External dimensions (mm) | 385 x 350 x 704 | 385 x 350 x 636 | 386 x 412 x 704 | 311 x 300 x 635 |
| Weight (kg) | 28 | 30 | 30 | 16 |
| Stylus | Tungsten carbide 60 mm | Tungsten carbide 60 mm | Tungsten carbide 60 mm | Tungsten carbide 80 mm |
| Column stroke / passage | Column stroke 270 mm max. | Motorized Z-axis stroke 250 mm | Column stroke 270 mm max. | Passage under head 280 mm (up to 300 mm with 60 mm stylus) |
| Machine / controller cable length | 2.5 m | 2.5 m | 2.5 m | 2.5 m |
| Controller | e10 controller | e10 controller | e10 controller | ec1 controller |
