Specifications
Model Specification Table
| Parameter | Value | Unit |
|---|---|---|
| Maximum Turning Diameter | Ø530 (Main) / Ø530 / Ø410 (Main / Sub) | mm |
| Maximum Turning Length | 591 / 591 / 579.5 (Main / Sub) | mm |
| Chuck Size | 6 (OPT: 8) / 6 (OPT: 8) / 6 (Main / Sub) | inch |
| Spindle Bore | Ø62 / Ø56 (Main / Sub) | mm |
| Bar Capacity | Ø51 / Ø45 (Main / Sub) | mm |
| Spindle Speed | 6,000 / 6,000 (Main / Sub) | rpm |
| Spindle Motor Power | 11 / 7.5 (15 / 10) / 11 / 7.5 (15 / 10), 7.5 / 5.5 (10 / 7.4) (Main / Sub) | kW (HP) |
| Number of Turret Stations | 18 | stations |
| Axis (X/Y/Z/B) | 310 / ±50 / 700 / 750 | mm |
| CNC Controller | Fanuc 0i-TF Plus | — |
| Turnmill | 5.5 / 3.7 (7.4 / 5), 4,000 | kW (HP), rpm |
| Sub Spindle | 7.5 / 5.5 (10 / 7.4), 6,000 | kW (HP), rpm |
| Turret | Capto C4 / BMT 55 | — |
Core Capabilities
Complete Machining Capabilities
Achieve precision and efficiency with full multi-axis machining in a single setup.
